Bardwell Lake: 91.6% full as of 2024-11-20

The elevation-storage rating curve used to produce the storage hydrograph is made of two segments: (1) the segment up to the conservation pool top (below the red line) is based on measured data, and (2) the segment in the flood pool (above the red line) is an extrapolation from the first segment and shouldn't be relied upon for flood storage information.

Historical Data

Date Percent Full Mean Water Level
(ft) 		Reservoir Storage
(acre-ft) 		Conservation Storage
(acre-ft) 		Conservation Capacity
(acre-ft) 		Surface Area
(acres)
Most recent 2024-11-20 91.6 419.86 40,248 40,187 43,856 3,145
1 day prior 2024-11-19 91.6 419.85 40,216 40,155 43,856 3,144
2 days prior 2024-11-18 91.4 419.83 40,154 40,093 43,856 3,142
1 week prior 2024-11-13 91.9 419.90 40,374 40,313 43,856 3,151
1 month prior 2024-10-20 91.7 419.87 40,279 40,218 43,856 3,147
3 months prior 2024-08-20 99.5 420.93 43,687 43,626 43,856 3,283
6 months prior 2024-05-20 100.0 435.16 104,522 43,856 43,856 5,378
1 year prior 2023-11-20 100.0 421.45 45,415 43,856 43,856 3,349
*

Percent Full is based on Conservation Storage and Conservation Capacity and doesn't account for storage in flood pool.

**

   Values above, including today's are averaged conditions. For near real-time instantaneous water level, see table below or the interactive map viewer.

Most Recent Instantaneous Water Level

Date/time Water Level
(ft) 		Conservation Pool Elevation
(ft) 		Height Above Conservation Pool
(ft)
Most recent 2024-11-20 23:30 419.81 421.00 -1.19 below flood pool
1 hour prior 2024-11-20 22:30 419.81 421.00 -1.19 below flood pool
2 hours prior 2024-11-20 21:30 419.82 421.00 -1.18 below flood pool
6 hours prior 2024-11-20 17:30 419.81 421.00 -1.19 below flood pool
12 hours prior 2024-11-20 11:30 419.85 421.00 -1.15 below flood pool
24 hours prior 2024-11-19 23:30 419.88 421.00 -1.12 below flood pool
48 hours prior 2024-11-18 23:30 419.85 421.00 -1.15 below flood pool
*

Data is provisional and subject to revision.

Additional Information

Impoundment date 1965-01-01
Vertical datum NGVD29
Dead pool elevation 391.00 ft above NGVD29
Service spillway crest elevation 439.00 ft above NGVD29
Emergency spillway crest elevation 439.00 ft above NGVD29
Flood pool elevation 439.00 ft above NGVD29
Maximum design elevation 455.90 ft above NGVD29
Top of dam elevation 460.00 ft above NGVD29
Conservation pool elevation 421.00 ft above NGVD29
Data download (CSV) period of record, last one year, last 30 days

Elevation-Area-Capacity Curves

1999-02-01 (source: TWDB) : GIS Data
2020-07-01 (source: TWDB) : GIS Data
Data Source USGS:08063700
